PE Jaw Crusher

Jaw crusher is a high-efficiency and reliable crushing equipment widely used in industries such as mining, metallurgy, and construction materials. It crushes large materials into smaller particles through the relative motion of two jaw plates, featuring a high crushing ratio and robust durability. This equipment is easy to operate and maintain, making it an ideal crushing solution for your needs.

  • ≤ 1020 mm
  • 2-1000t/h
  • sale3@olivetech.cn
  • 0086 16638156296
  • Information
  • Video

  Jaw Crusher




Product introduction

Feed Size: ≤ 1500mm
Production Capacity: 1-1000t/h
Application Range: Metallurgy, chemical industry, building materials, electric power, transportation, and other industrial sectors.
Applicable Materials: Granite, dolomite, pebble, quartz stone, calcite, and other materials.

The jaw crusher is an essential piece of equipment in the ore crushing process, particularly important in the crushing production line. Olive Technology's jaw crushers have undergone continuous innovation and process improvements, leading to significant advancements in structure and technology. The jaw crusher features a simple structure, reliable operation, ease of use, convenient maintenance, and lower costs.



Product Parameters



Model

Size (mm)Feed Opening Size (mm)Max Feed Size (mm)Discharge Adjustment Range (mm)



Capacity (t/h)

Main Shaft Speed (r/min)Motor Power (kW)Machine Weight (kg)
LengthWidth
PE-150150*250 250150 12515-451.7-5.62855.51000
PE-200200*300 300200 18020-50 3.5-13.528511 1500
PE-250250*400 400250 210 20-60 5-22 300 15 2800
PE-400400*600 600400 340 40-80 18-60 275 30 7000
PE-500500*750 750 500 425 50-100 43-102 275 55 13500
PE-600600*900 900 600 500 65-180 51-145 250 75 19200
PE-750750*1060 1060 750 630 80-180 122-223 250 110 29000
PE-900900*1200 1200 900 780 95-180 285-430 200 132 45000
PE-10001000*1200 1200 1000 850 195-280 320-470 200 132 51000
PE-12001200*1500 1500 1200 1020 150-300 425-765 180 160 100900




Application Field

PE jaw crusher is commonly used throughout the industry to reduce the pieces into the required sizes and to impart fineness to the broken material with high quality and efficiency.

Use effect of jaw crusher1727582522662.jpg

Jaw crushers are mainly used for medium-sized crushing of various ores and bulk materials and are mostly used in mining, smelting, building materials, highways, railways, water conservancy, and chemical industries.


Machine Structure and Working Principle

When the jaw crusher is working, the movable jaw moves periodically to and fro the fixed jaw, sometimes proaching and sometimes leaving. When approaching, the material is crushed due to compression, splitting, and impact between the two jaw plates; When leaving, the crushed material is discharged from the discharge port by gravity.

Principle of jaw crusher

Jaw crusher Working Principle

 Patent

Grease Injection Device [Patent No. 10-0614520]
Design of Fixed Jaw Plate [Patent No. 10-0614896]
Crushing Chamber Setting Adjustment [Patent No. 10-1965851]
